In each case the core PSCC element of the product remains unaltered. The Ap800-PSCC is suitable for use with the entire Ap800 range of printers, including the Ap863-F, Ap890 and Ap892. The Ap1200-PSCC is suitable for use with the Ap1200 panel mounted printer. 2.1 PSCC / PRINTER COMBINATIONS The PSCC unit is currently available in two forms.
PARALLEL TO SERIAL CONVERTER WITH BUFFER FULL
Full details of the operation of ABLE Systems printers are provided in separate User Guides.
Please read this Guide carefully before making any connection.
2004Ģ 1 TABLE OF CONTENTS 1 Table Of Contents Introduction PSCC / Printer Combinations Copyright and Confidentiality Notice EMC Disclaimer Documentation Revision History Operation and Connections Mode of Operation Parallel Input (PC "D-25") Connections Exceptions to Centronics Standard Connections Power Arrangements Buffer Size, Serial Output Baud Rate and Data Throughput Serial Output Connections (Ap1200-PSCC Version) Serial Output Connections (Ap800-PSCC Version) Further Information On-Line Information If All Else Fails Combined PSCC User Information - Revision of 6ģ 2 INTRODUCTION This document is a User Guide, written for the person connecting and using the ABLE Systems PSCC (Parallel to Serial Convertor Cable) in conjunction with an appropriate ABLE Systems printer. 1 ABLE Systems Limited DENTON DRIVE, NORTHWICH, CHESHIRE, CW9 7TU, ENGLAND Tel: +44 (0) Fax:+44 (0) Website: USER INFORMATION for PSCC Parallel to Serial Convertor Cable (Including Specific Information for "Ap1200-PSCC" and "Ap800-PSCC") Revision: 1.2 Filename: Comb_PSCC_UI(1.2).doc Date: 29 Mar.
